FreeScan X5+ Wireless Laser Handheld 3D Scanner

FreeScan X5+ Wireless Laser Ha

Description
Specs
Enquiry
Features

GO WIRELESS
Redefining the portability of handheld 3D scanners.
Brings you true freedom in 3D scanning.

Specification

Weight:0.95 kg
Dimension:130 x 90 x 310 mm
Light Source:14 line laser ray, Class II ( eye safe )
Scan Speed:480, 000 scans/s
Scan Range:300×275mm
Resolution:0.05 mm
Measuring Accuracy:0.03 mm
Volumetric Accuracy:0.02 mm+0.06 mm/m
Volumetric Accuracy (Combined with DigiMetric):0.020 mm+0.025 mm/m
Scan Range (Object size):100-8000 mm ,extensible
Connection Standard:USB3.0/WiFi
Components:AirMaster, USB- air line, Battery*3, Charger
Airmaster-Weight:0.8 kg (including battery)
Airmaster-Size:210 x 100 x 40 (mm)
Airmaster-Battery Capacity:2100 mAh
Airmaster-Sustainable Working Hours:3h
Airmaster-Standby Time:12h
Airmaster-Wireless Mode:802.11n/ac
Data compatible software:3D Systems（Geomagic Solutions）、InnovMetric Software（PolyWorks）、Dassault Systemes（CATIA V5 and SolidWorks）、PTC（Pro/ENGINEER）、Siemens（NX and Solid Edge）、Autodesk（Inven

Unlimited 3D Scanning :
Without the need of cables to connect to computers, you can enjoy complete freedom of 3D scanning.
Real-time visualization :
Real-time data display on your smartphone or tablet, for ease of scanning of large objects and scenes.
Portable and user-friendly :
Light-weight 3D scanner & “AirMaster”, intuitive workflow for easy operation.
Long battery life :
Adaptable to measurement tasks in indoor, outdoor and other complex environment;
Advanced operation :
AirMaster wireless computational processor, with a built-in heterogeneous multi-core SOC processor, offers a calculation of image data completely driven by the hardware.
